產品詳情
高兆帕鍛鋼止回閥的介紹視頻：
主要外形尺寸和重量
| 公稱通徑DN(mm) | G | d | L | H | Cv | WT(kg) |
| H14W-16P H14W-16T H14W-25P H14W-25T | ||||||
| 15 | 1/2" | 15 | 65 | 44 | 6.9 | 0.6 |
| 20 | 3/4" | 20 | 80 | 53 | 16.3 | 0.8 |
| 25 | 1'1 | 25 | 90 | 58 | 30.0 | 1.5 |
| 32 | 1 1/4" | 32 | 105 | 62 | 49.0 | 2.0 |
| 40 | 1 1/2" | 38 | 120 | 73 | 72.0 | 3.2 |
| 50 | 2" | 50 | 141 | 78 | 130.0 | 5.0 |
| 公稱通徑DN(mm) | G | d | L | H | H1 | □S | WT(kg) |
| H13W-10T H13T-10H13W-10PH13W-10R | |||||||
| 15 | 1/2” | 14 | 85 | 73 | 26 | 11 | 0.6 |
| 20 | 3/4" | 16 | 90 | 95 | 34 | 14 | 1.0 |
| 25 | 1" | 18 | 110 | 95 | 38 | 17 | 1.5 |
| 32 | 1 1/4” | 20 | 130 | 107 | 45 | 19 | 2.5 |
| 40 | 1 1/2” | 22 | 150 | 157 | 55 | 22 | 4 |
| 50 | 2" | 24 | 170 | 186 | 74 | 27 | 7 |
| 65 | 2 1/2" | 26 | 220 | 213 | 82 | 32 | 11.5 |
| 80 | 3" | 30 | 250 | 202 | 125 | 36 | 16.5 |
| 100 | 4" | 30 | 300 | 290 | 135 | 46 | 22 |
